11kV Compact Box Substation
Lub thawv compact substation yog lub Hoobkas prefabricated sab hauv tsev thiab sab nraum zoov cov khoom siv hluav taws xob sib xyaw ua ke uas sib txuas cov hluav taws xob hloov hluav taws xob, cov khoom siv hluav taws xob faib hluav taws xob thiab cov khoom siv hluav taws xob tsawg hluav taws xob raws li cov txheej txheem xaim. Kev siv ib txwm muaj Altitude: Tsis yog ...
Hauj lwm lawm
Lub thawv compact substation yog lub Hoobkas prefabricated sab hauv tsev thiab sab nraum zoov cov khoom siv hluav taws xob sib xyaw ua ke uas sib txuas cov hluav taws xob hloov hluav taws xob, cov khoom siv hluav taws xob faib hluav taws xob thiab cov khoom siv hluav taws xob tsawg hluav taws xob raws li cov txheej txheem xaim.
| Serial Number | Lub npe | Chav tsev | High voltage apparatus | Hloov pauv | Tsawg voltage hluav taws xob apparatus |
| 1 | Rated voltage | KV | 6/10 | 6/0.4 10/0.4 | 0.4 |
| 2 | Rated peev | KVA | 50∼1600 | ||
| 3 | Rated tam sim no | A | 200,400,630 | 100∼3200 | |
| 4 | Rated luv-circuit breaking tam sim no | A | Load hloov 400∼630 | 15 ~ 63 KV | |
| KA | Qhov sib xyaw ua ke yog nyob ntawm lub fuse | ||||
| 5 | Rated luv-lub sij hawm tiv taus tam sim no | KA | 16,20(4S) | 15 (1S) | |
| 30 (1S) | |||||
| 6 | Rated ncov tiv taus tam sim no | KA | 31.5,50 | 30 | |
| 63 | |||||
| 7 | Fais fab zaus withstand voltage (1MIN) | KV | Theem rau hauv av thiab theem mus rau theem 32/42 | 25/35 (Oil raus) | Tsawg dua lossis sib npaug rau 0.3, 2 |
| Isolation chaw nres nkoj 36/48 | 20/28 (Nyob) | >0.3, 2.5 | |||
| 8 | Lightning impulse withstand voltage (nce tus nqi) | KV | Theem rau hauv av thiab theem mus rau theem 60/75 | 60/75 | |
| Isolation chaw nres nkoj 70/85 | |||||
| 9 | Box tiv thaiv qib | IP23 | |||
| 10 | Lub suab nrov | ab | 55 | ||
| 11 | Tus txheej txheem tswj hwm | GB / T 17467 "High voltage thiab low voltage prefabricated substation" |
Ib txwm siv tej yam kev mob
Qhov siab: Tsis pub tshaj 1000M;
ambient kub: -25 degree ~ 40 degree;
txheeb ze av noo: Qhov nruab nrab txhua hnub tsis ntau tshaj 95 feem pua, qhov nruab nrab txhua hli tsis tshaj 90 feem pua;
Qhov chaw teeb tsa: Qhov chaw tsis muaj hluav taws kub, muaj kev phom sij tawg, cov plua plav conductive, tshuaj lom neeg corrosive gas thiab kev co hnyav.
Yog tias cov xwm txheej saum toj no dhau lawm, tus neeg siv yuav tsum sib tham nrog peb lub tuam txhab.
