10.5KV 125KA KYN28A Kev Nyab Xeeb MV Switchgear

10.5KV 125KA KYN28A kev nyab xeeb MV switchgear

KYN series hlau-clad tshem tau enclosed hloov txee (hu ua hloov txee rau luv). Nws muaj feem xyuam rau lub zog txais

thiab kev faib tawm hauv 3.6-12Kv peb-theem AC 50Hz ib lub tsheb npav thiab ib lub tsheb npav ib ntus. Nws muaj cov haujlwm ntawm

tswj, tiv thaiv thiab saib xyuas lub Circuit Court.

1, Cov khoom ntawm high-voltage switchgear txee lub cev

1. Txias dov steel phaj los yog lub kaum sab xis steel (siv rau vuam khoom);

2. Aluminium zinc coated steel phaj los yog galvanized steel phaj (siv rau assembling txee)

3. Stainless hlau phaj (tsis sib nqus)

4. Aluminium phaj (tsis sib nqus)

2, Kev ua haujlwm ntawm high-voltage switchgear:

1. Lub tsheb npav tseem ceeb (feem ntau teem rau hauv ob lub qauv: "pin" lossis "1")

2. Circuit Court breaker chav

3. Chav Cable

4. Relay thiab ntsuas chav

5. Txee sab saum toj me me busbar chav

6. Thib ob lub davhlau ya nyob twg compartment

3, Muaj nuj nqi ntawm lub switchgear

Lub switchgear muaj cov haujlwm xws li nyiaj siv ua haujlwm sab hauv thiab sab nraud, cov kab nkag thiab tawm, thiab kev sib txuas ntawm busbar.

4, Kev sib xyaw ntawm switchgear

Lub switchgear yuav tsum ua kom tau raws li qhov yuav tsum tau muaj ntawm GB3906-1991 "3-35 kV AC Hlau Enclosed Switchgear" tus qauv, muaj ob ntu: lub txee lub cev thiab Circuit Court breaker. Lub txee lub cev yog tsim los ntawm lub plhaub, cov khoom siv hluav taws xob (nrog rau cov khoom siv rwb thaiv tsev), ntau yam txheej txheem, cov khoom siv thib ob, thiab cov xov hlau.

Tsib kev tiv thaiv rau high-voltage switchgear

1. Tom qab lub tshuab nqus tsev Circuit Court breaker lub tsheb nyob rau hauv lub high-voltage switchgear kaw nyob rau hauv lub xeem txoj hauj lwm, lub tsheb Circuit Court breaker tsis tuaj yeem nkag mus rau txoj haujlwm ua haujlwm. (Tsis txhob kaw qhov load)

2. Thaum lub hauv paus hloov mus rau hauv lub high-voltage switchgear nyob rau hauv qhov chaw kaw, lub tsheb Circuit Court breaker yuav raug kaw. (Tsis txhob kaw nrog grounding hlau)

3. Thaum lub tshuab nqus tsev Circuit Court breaker nyob rau hauv high-voltage switchgear raug kaw, lub qhov rooj rov qab ntawm lub vaj huam sib luag thiab txee yog xauv nrog ib tug neeg kho tshuab cuab yeej ntawm lub hauv paus riam. (Txhawm rau tiv thaiv kev nkag mus rau hauv qhov chaw nyob)

4. Lub tshuab nqus tsev Circuit Court breaker hauv high-voltage switchgear raug kaw thaum lub sijhawm ua haujlwm, thiab qhov hloov hauv av tsis tuaj yeem muab tso rau hauv kev ua haujlwm. (Tsis txhob nyob dai ntawm cov xaim hauv av)

5. Lub tshuab nqus tsev Circuit Court breaker hauv high-voltage switchgear tsis tuaj yeem tawm ntawm qhov chaw ua haujlwm ntawm lub trolley circuit breaker thaum nws ua haujlwm thiab kaw. (Yuav kom tiv thaiv cov riam nres)

Main technical parameters
Rated voltage	.....................................	kV ua	3.6,7.2,12
Rated zaus	.....................................	Hz	50
Rated tam sim no ntawm Circuit Court breaker	.....................................	A	630/4000
Rated tam sim no ntawm switchgear	.....................................	A	630/4000
Rated luv-lub sij hawm tiv taus tam sim no (4S)	.....................................	kA	20,25,31.5,40
Rated ncov withstand tam sim no (peak)	.....................................	kA	50,63,80,100
Rated luv-circuit breaking tam sim no	.....................................	kA	20,25,31.5,40
Rated rwb thaiv tsev theem 1min zog zaus withstand voltage	Ncej-rau-ncej, ncej-rau- av	kV ua	24,32,42
	Nruab nrab ntawm kev sib cuag qhib	kV ua	24,32,48
Lightning impulse withstand voltage (nce)	Ncej-rau-ncej, ncej-rau- av	kV ua	40,60,75
	Nruab nrab ntawm kev sib cuag qhib	kV ua	46,70,85
Lub plhaub yog IP4X, thiab nws yog IP2X thaum lub qhov rooj qhov rooj thiab lub qhov rooj kaw qhov rooj qhib

Nta

1: STRICT tiv thaiv kauj ruam kom paub meej txog kev nyab xeeb ntawm tus kheej

2: Chav tsev cable tuaj yeem ntsia tau ntau npaum li 9 tus tub ntxhais cables

3: Kev khiav hauj lwm thiab kev soj ntsuam txoj haujlwm yuav raug tsim tsa rau lub laub, thiab ob txoj haujlwm tau nruab nrog kev ruaj ntseg thiab txhim khu kev qha cov cuab yeej thiab cov khoom siv.

4: Lub thawv ntim tau ua tiav los ntawm aluminized thiab galvanized steel phaj, uas yog machined thiab khoov los ntawm lub tshuab cuab yeej thiab ces bolted.

5: Nws muaj lub zog txhua yam thiab nws qhov zoo nkauj thiab kev zoo nkauj tau lees paub.

6: Lub qhov rooj switchboard yog txau nrog cov yas, kuj muaj lub peev xwm ntawm kev cuam tshuam thiab kev tiv thaiv corrosion.

7: Cov kev hloov pauv tseem ceeb tuaj yeem muab nrog VD4 lub tshuab nqus tsev vacuum thiab C3 series ntawm kev hloov pauv hloov ntawm ABB, ntau lub tshuab nqus tsev hluav taws xob hauv tsev (xws li VS1, VH1, VK, ZN28) kuj tseem tuaj yeem muab rau ntawm tib neeg txawv teb chaws. cov khoom.

8: Pem hauv ntej lub qhov rooj yog ntsia nrog lub qhov rais soj ntsuam xyuas cov kev khiav hauj lwm lub xeev ntawm cov khoom nyob rau hauv lub chav tsev

Kev Pabcuam

◎ Ambient cua kub: -15 degree ~ ntxiv rau 40 degree ;

◎ txheeb ze av noo: nruab nrab txhua hnub 95 feem pua, thiab nruab nrab txhua hnub ntawm cov dej vapor siab <2.2kPa;

◎ Qhov nruab nrab txhua hli «90 feem pua, thiab txhua hli nruab nrab ntawm cov dej vapor siab <1.8kPa;

© Qhov siab: ^ 1000m;

◎ Seismic siv: tsis dhau Ms8.

◎ Cov huab cua nyob ib puag ncig yuav tsum tsis muaj kuab paug ntawm corrosive lossis flammable gas lossis vapor;

◎ Tsis pom kev vibration;

PRODUCT PHOTO

CHAW UA HAUJ LWM

CERTIFICATE

EXHIBITION

PACKING & xa khoom

FAQ

Q3: Lub sijhawm khoom xa tuaj yog dab tsi? Vim peb yeej xav tau lawv yog urgently?

A: 3 ~ 7 hnub Rau kev xa cov qauv txiav txim. .15 hnub rau kev txiav txim tsis tu ncua, peb yuav tsis noj peb cov lus.

Q4: Lub sijhawm lav rau koj cov khoom yog dab tsi?

A: Rau ib xyoos warranty.

Q5: Puas yog OEM / ODM muaj?

A: Yog, nws yog! Peb cov khoom tuaj yeem tsim kho. Peb muaj pab pawg tsim thiab engineers, peb tuaj yeem kho cov khoom raws li cov neeg siv khoom kos duab lossis cov kev xav tau.

Q6: Koj puas yog cov chaw tsim khoom lossis tuam txhab lag luam?
A: Peb yog lub Hoobkas, Raws li 100 feem pua ​​​​ntawm cov chaw tsim khoom nrog 20 xyoo kev tsim khoom, peb tuaj yeem tsim cov khoom raws li cov neeg siv khoom xav tau thiab peb tuaj yeem tswj cov khoom zoo 100 feem pua.

Q7: Tus nqi puas tuaj yeem sib tham?

A: Yog, tus nqi sib tham. Nws tuaj yeem hloov pauv raws li koj qhov ntau lossis pob

Q8: Ua li cas txog kev tshuaj xyuas?

A: Peb muaj tag nrho cov kev tshuaj xyuas los ntawm cov khoom siv raw mus rau qhov kawg cov khoom suav nrog kev ntsuas kub nce, ntsev tsuag tshuaj ntsuam xyuas tus neeg xyuas pib hom kev xeem, kev sim lub neej.

Q9: Cov nqe lus them nqi yog dab tsi?

A: TT, Paypal, Western Union, Alibaba kev lees paub kev lag luam thiab L / C tau txais. 30 feem pua ​​​​T / T ua ntej, 70 feem pua ​​​​ua ntej xa zaub mov.

Q10: Lub tuam txhab muab kev pabcuam yog dab tsi?

A: Peb muaj cov kws tshaj lij engineer pab pawg uas tuaj yeem tsim thiab tsim pwm kom tuaj txog cov neeg siv khoom sib txawv.

Peb kuj muaj pab pawg muag khoom los muab kev pabcuam zoo los ntawm kev muag khoom ua ntej mus rau tom qab muag.

Cov khoom no feem ntau yog customized.
Peb yog cov chaw tsim khoom thiab muaj lub tuam txhab kev tshaj lij uas tuaj yeem tsim thiab muab kev daws teeb meem raws li cov neeg siv khoom xav tau.
Thov hu rau peb cov neeg muag khoom kom tau txais cov duab kos duab

Nov yog peb cov neeg siv khoom piv txwv rau koj siv


Uzbekistan cov neeg siv khoom

Kev tsim kho ntawm Boysun GPP
Cov ntaub ntawv thov rau
Nruab nrab Voltage Switchgears
6 / 20 BGPP-UZLE-D-200-000-0-EL-REQ-10011-E-A1
2. KEV PAB CUAM
Nyob rau hauv tshooj no, VENDOR cov peev txheej ntawm cov khoom yuav tsum suav nrog, tab sis tsis txwv rau, ua tiav kev tsim, engineering,
Kev tsim khoom, tsim khoom / tsim khoom, yuav tawm cov khoom, sib dhos hauv khw, khw muag khoom &
kuaj, nto npaj & painting, preservation, packing thiab tsheb thauj mus los, cov ntaub ntawv, mov thiab
kev pab txhawb nqa (ntawm ib tus nqi diem), muab tag nrho kev ua haujlwm lav rau Medium Voltage Switchgears li
ib daim ntawv teev cov ntaub ntawv, specifications thiab tag nrho cov Codes & Standards.
Txoj kev no tseem yuav suav nrog rau cov khoom siv ntxiv thiab cov kev pabcuam uas xav tau kom muaj kev nyab xeeb thiab txaus siab
Kev ua haujlwm ntawm Medium Voltage Switchgears. Ua kom tiav cov ntsiab lus ntawm tag nrho cov khoom no qhia txog cov laj thawj rau
suav nrog yuav tsum tau muab tso rau hauv qhov kev sib tw
2.1. Yam khoom thiab QUANTITY
Tag nrho cov ntaub ntawv yuav tsum tau muab tso rau hauv raws li cov cai, cov qauv thiab cov ntaub ntawv uas txuas / teev nyob rau hauv
daim ntawv thov no.
Yam khoom
Tsis muaj.
Tag No./ Location Description Qty.
MEDIUM VOLTAGE SWITCHGEARS
1 General Parameters qhia nyob rau hauv nqe lus no yog qhov zoo rau tag nrho MV Switchgears thiab
MV breaker cubicles
• Hom: AIS, Hlau clad
• Voltage: 10.5 kV
• Zaus: 50Hz
• Tswj mov: 110V DC
• Pab: 230V AC
• Busbar: Insulated
• Isc /sec. (Ik"): 50kA / 3sec, ALFR
• Ipeak (Ip): 125kA
• Kev tiv thaiv Ingress: IP42 / IP20 (raws li kab lus 6.81 ntawm doc.
BGPP-UZLE-D-200-000-0-EL-SPE-00006)
• Anti-condensation rhaub: Yuav tsum tau.
• Surge arrester: Yuav tsum muaj rau txhua tus feeders raws li SLD
BGPP-UZLE-D-200-512-0-EL-SLD-10101
• Kev tsim kho : thim tau
• 52-MOCa : Yuav tsum tau
• 52-MOCb : Yuav tsum tau
• Poob Kev Pabcuam Pawg: LSC2B
• Lightning Impulse withstand voltage : As per Table -1 of IEC-62271-1
• Lub zog zaus tiv taus qhov hluav taws xob: Raws li cov lus -1 ntawm IEC-62271-1
• Metering tam sim no transformers : 1A theem nrab, Chav kawm =0.5, ISF<5
