40.5kv Tshem Tawm Sab Hauv Tsev AC Hlau-enclosed KYN Switchgear

40.5kv Tshem Tawm Sab Hauv Tsev AC Hlau-enclosed KYN Switchgear



Qauv	KYN61-40.5
Rated voltage	40.5
Ntau zaus	50 HZ
Rated Tam sim no	1250A/1600A/2000A
IP Qib	IP3X
Ib puag ncig kub	-10 C ~ ntxiv 40 C
Khoom siv	specification
Kev Qhia Txog Kev Kho Mob	Yuav tsum tau ntxuav thiab muab tso rau hauv qhov chaw qhuav



KYN61-40.5 tshem tau AC hlau-clad switchgear siv rau 40.5kV, 3 theem, AC thiab 50/60Hz hluav taws xob hluav taws xob network rau kev txais thiab xa tawm lub zog hluav taws xob thiab tseem rau kev tswj, saib xyuas thiab tiv thaiv ion. Nws muaj feem xyuam rau lub zog dav dav thiab lub sijhawm nrog kev ua haujlwm nquag. Cov khoom ua raws li GB3906: 3 ~ 35kV AC Hlau Enclosed Switchgear, IEC60694 & GB/T11022: Cov lus qhia dav dav ntawm HV Switchgear thiab controlgear Standard, DL / T404-1997: Order Technical term of Indoor AC HV Switchgear thiab IEC 62271-200 1~ 52kV AC Hlau Enclosed Switchgear thiab tswj tus qauv.



Ib puag ncig tej yam kev mob



1) Qhov ntsuas kub tsim nyog: -10 degree ~ ntxiv rau 40 degree, qhov nruab nrab nruab nrab txhua hnub: Tsawg dua lossis sib npaug li 35 degree .



2) Haum Qhov siab: Tsawg dua lossis sib npaug li 1000m



3) Tus txheeb ze Humidity: Txhua hnub txhais tau tsawg dua lossis sib npaug li 95 feem pua, txhua hli txhais tau tsawg dua lossis sib npaug li 90 feem pua



4) Kev puas tsuaj ntawm av qeeg: Tsawg dua lossis sib npaug rau Qib 8



Cov sij hawm siv tau yuav tsum tsis muaj corrosives, inflammables thiab vapors.



Cov ntsiab lus:

KYN 61-40.5 switchgear yog peb theem AC 50 Hz, ntsuas qhov hluav taws xob ntawm 40.5 KV cov khoom siv hluav taws xob sab hauv tsev.Raws li cov chaw tsim hluav taws xob, cov chaw siv hluav taws xob thiab kev lag luam kev puas tsuaj ntawm hluav taws xob hluav taws xob nkaus xwb, thiab muaj kev siv hluav taws xob hauv hluav taws xob, kev tiv thaiv thiab saib xyuas muaj nuj nqi.

Structure Description:



Switchgear raws li G83906 thiab IEC298 tus qauv thiab tsim, Thiab tuaj yeem raug tshem tawm ntawm lub txee raws li tag nrho chav tsev (trolley) cov khoom.
Txee qauv yog ua los ntawm txhuas deposited zine phaj los yog galvanized ntawv sib sau ua ke nrog ob qho tib si kev twb kev txuas, cais Circuit Court breaker switchgear roon, tsheb npav chav tsev, cable chav thiab ntsuas chav tsev, Tag nrho cov hlau Cheebtsam yog grounded, txhua compartment ntawm lub ntsiab Circuit Court .system muaj cais siab tso tawm. channel nyob rau hauv lub cable compartment yuav teem 10 * 60mm av tsheb npav .

Cov yam ntxwv tseem ceeb:

1.Kev siv cov khoom sib dhos ua ke, Circuit Court breaker handcart floorstanding qauv,
Loj loj:
2.Optional: Lub tuam txhab lub tshuab nqus tsev vacuum VW1-40.5,xiamen huadian nqus tsev vacumm breaker VEP-40.5, zoo ib yam li Circuit Court breaker yog interchangeable .
3.Txhim kho cov tsheb thauj khoom tshwj xeeb tuaj yeem nqa, tsheb thauj mus los amd txee kom raug qhov chaw, xauv thiab txhim khu kev qha
4.Lub ntsiab hloov, lub tawb nqa khoom, qhov rooj sib cuam tshuam ntawm qhov yuav tsum tau siv lub tshuab ntsuas phoo yog siv los ua kom tau raws li 'Tsib Anti' cuam tshuam.
5.Txhua txoj haujlwm tuaj yeem ua tiav ntawm lub qhov rooj kaw lub xeev, los tiv thaiv kev nyab xeeb ntawm tus neeg teb xov tooj.
6.Cable qhov chaw txaus, tuaj yeem txuas nrog ntau lub cables, thiab cov khoom siv hluav taws xob.
7.Shell tiv thaiv qib IP3X, handcart chav qhov rooj qhib nruab nrab ntawm ntau yam kev tiv thaiv chav kawm IP2X.
8.Cov ntaub ntawv tuaj yeem ua cov ntawv galvanized tuaj yeem tso rau alumimum zinc phaj ntau lawm.



2.Main Electric Parameters

Tsis muaj.	Cov khoom			Chav tsev	Tsis muaj
1	Rated voltage			KV	40.5
2	Rated zaus			Hz	50
3	Lub ntsiab busbar ntsuas tam sim no			A	1250,1600,1200
4	Ceg busbar ntsuas tam sim no			A	630/1250/ 1600
5	Rated rwb thaiv tsev theem	Fais fab zaus withstand voltage nyob rau hauv 1min (zoo tus nqi)	Phase-phase, Phase-hauv av	KV	95
			Kev sib cais thawj zaug	KV	115
		Lightning Impulse Withstand Voltage (tus nqi siab tshaj)	Phase-phase, Phase-hauv av	KV	185
			Kev sib cais thawj zaug	KV	215
		Fais fab zaus withstand voltage ntawm pab tswj Circuit Court		V	2000
6	Rated luv Circuit Court breaking tam sim no			KA	25/31.5
7	Rated luv Circuit Court kaw tam sim no (peak tus nqi)			KA	63/80
8	Rated luv-lub sij hawm tiv taus tam sim no (4S)			KA	25/31.5
9	Rated ncov tiv taus tam sim no			KA	63/80
10	Rated voltage ntawm pab tswj Circuit Court			V	-110,-220,~220
11	Qib tiv thaiv				Enclosure IP4X, IP2X Thaum lub qhov rooj ntawm Circuit Court breaker qhib
12	Qhov loj me (dav * qhov tob * qhov siab)			mm	1400 (1200) * 2800 (2600) * 2600 (* suav nrog cov txheej txheem SF6 sab hauv)
13	hnyav			kg	~2300



1, Kev tu thiab kho txhua hnub

(1) Kev tshuaj xyuas qhov tshwm sim ntawm lub switchgear.

Lub plhaub ntawm lub switchgear yuav tsum tsis txhob deformation thiab puas; Cov xim tiv thaiv tsis muaj xeb loj, puas, thiab tev; Lub txee lub cev yog ruaj khov, thiab cov tsos yog huv si thiab tsis muaj khib nyiab; Daim ntawv teev npe thiab kev txheeb xyuas ntawm lub switchgear yuav tsum tau muab pov tseg kom zoo yam tsis muaj detachment.

(2) Txheeb xyuas cov xwm txheej ua haujlwm ntawm lub switchgear.

Cov ntsuas ntsuas thiab ntsuas ntsuas yog qhov qub (piv rau cov txiaj ntsig kev ua haujlwm niaj hnub, tsis muaj qhov sib txawv lossis tsis muaj qhov sib txawv tseem ceeb thiab sib haum rau cov khoom siv).

(3) Cov khoom tseem ceeb, kev sib cuag hluav taws xob, cov xov hlau, thiab cov kab hluav taws xob ntawm lub tshuab hluav taws xob yuav tsum tsis pub tshaj qhov ntsuas kub.

Siv lub ntsuas kub infrared los ntsuas qhov ntsuas kub ntawm kev ua haujlwm ntawm cov khoom siv pom, cov hluav taws xob tiv tauj, cov xov hlau, thiab cov cables kom tsawg dua lossis sib npaug li 60 degree, thiab tsis muaj ntxhiab tsw hauv lub txee.

(4) Seb qhov hloov txoj hauj lwm, qhov taw qhia lub teeb qhia thiab ntsuas ntsuas qhov tseeb, thiab seb txoj hauj lwm ntawm txhua qhov hloov pauv yog qhov qub.

Qhov qhib thiab kaw txoj haujlwm ntawm qhov hloov pauv yog qhov tseeb, tsis muaj lub suab ceeb toom, thiab qhov hloov pauv hloov mus rau hauv txoj haujlwm tau teev tseg.



































Q5: Puas yog OEM / ODM muaj?

A: Yog, nws yog! Peb cov khoom tuaj yeem tsim kho. Peb muaj pab pawg tsim thiab engineers, peb tuaj yeem kho cov khoom raws li cov neeg siv khoom kos duab lossis cov kev xav tau.



Q6: Koj puas yog cov chaw tsim khoom lossis tuam txhab lag luam?
A: Peb yog lub Hoobkas, Raws li 100 feem pua ​​​​cov chaw tsim khoom nrog 20 xyoo kev tsim khoom, peb tuaj yeem tsim cov khoom raws li cov neeg siv khoom xav tau thiab peb tuaj yeem tswj cov khoom zoo 100 feem pua.



Q7: Tus nqi puas tuaj yeem sib tham?

A: Yog, tus nqi sib tham. Nws tuaj yeem hloov pauv raws li koj qhov ntau lossis pob



Q8: Ua li cas txog kev tshuaj xyuas?

A: Peb muaj tag nrho cov kev tshuaj xyuas los ntawm cov khoom siv raw mus rau qhov kawg cov khoom suav nrog kev ntsuas kub nce, ntsev tsuag tshuaj ntsuam xyuas tus neeg xyuas pib hom kev xeem, kev sim lub neej.



Q9: Cov nqe lus them nqi yog dab tsi?

A: TT, Paypal, Western Union, Alibaba kev lees paub kev lag luam thiab L / C tau txais. 30 feem pua ​​​​T / T ua ntej, 70 feem pua ​​​​ua ntej xa zaub mov.



Q10: Lub tuam txhab muab kev pabcuam yog dab tsi?

A: Peb muaj cov kws tshaj lij engineer pab pawg uas tuaj yeem tsim thiab tsim pwm kom tuaj txog cov neeg siv khoom sib txawv.

Peb kuj muaj pab pawg muag khoom los muab kev pabcuam zoo los ntawm kev muag khoom ua ntej mus rau tom qab muag.





Cov khoom no feem ntau yog customized.
Peb yog cov chaw tsim khoom thiab muaj lub tuam txhab kev tshaj lij uas tuaj yeem tsim thiab muab kev daws teeb meem raws li cov neeg siv khoom xav tau.
Thov nyem rau ntawm lub pob hauv qab no txhawm rau xa cov ntaub ntawv rau peb, thiab peb cov neeg muag khoom yuav tiv tauj koj los muab cov duab kos rau koj

Nov yog peb cov neeg siv khoom piv txwv rau koj siv



Yog xav paub ntxiv, thov koj xav tias dawb hu rau peb

Cim npe nrov: 40.5kv tshem tau sab hauv tsev ac hlau-xws li kyn switchgear, Tuam Tshoj, manufacturers, lwm tus neeg, customized
