KYN28A-12 sab hauv hlau hlau armored tshem tau switchgear yog tsuas yog siv rau cov chaw tsim hluav taws xob, kev lag luam thiab kev lag luam mining, nrog rau cov chaw ua haujlwm thib ob hauv lub zog hluav taws xob rau kev sau hluav taws xob, kev sib kis, thiab pib ntawm cov motors loj. Ua raws li kev tswj hwm, kev tiv thaiv, kev saib xyuas lub sijhawm, thiab kev ntsuas. Nws muaj tsib qhov kev tiv thaiv ua tiav thiab tuaj yeem nruab nrog Zhejiang VS1 (ZN63A-12) lub tshuab nqus tsev Circuit Court breaker, nrog rau VD4 lub tshuab nqus tsev vacuum uas tsim los ntawm ABB, HS hom (ZN82-12) lub tshuab nqus tsev vacuum breaker tsim los ntawm Shanghai Fuji Electric Switch Co., Ltd., thiab VEP hom (ZN96-12) ​​nqus Circuit Court breaker tsim los ntawm Xiamen Huadian Switch Co., Ltd., Sino txawv teb chaws koom tes. Tam sim no, nws tau siv dav hauv kev lag luam 12KV.



1. Lub ntsiab lus qauv

KYN28A -12

Ib puag ncig cov yam ntxwv ntawm cov khoom siv armored: tshem tau cov ntsiab lus daws teeb meem: tus naj npawb tsim: sab hauv

2. Zuag qhia tag nrho qhov ntev ntawm lub txee: (tus qauv nyiaj siv ua haujlwm tshaj tawm txoj kab nkag thiab tawm; cable nkag thiab tawm kab tawm tswv yim)

* Cov qauv txheej txheem rau cable inlet thiab qhov hluav taws xob kab thiab cov khoom tiv tauj: dav 800 (1000) × 1500 tob × 2300 siab

* Cov txheej txheem txheej txheem rau nyiaj siv ua haujlwm cov kab nkag thiab tawm: dav 800 (1000) × Qhov tob 1660 × 2300 siab

Lus Cim: 1. GZS1 ntxiv rau cable inlet thiab qhov hluav taws xob kab thiab tiv tauj txee txheem txheej txheem: dav 650 × 1500 tob × 2300 siab; Qhov sib nrug ntawm theem yog 150mm; Cov theem sib nrug ntawm GZS1 txee nrog qhov dav ntawm 800 yog 210mm; Qhov sib nrug ntawm cov txee nrog qhov dav ntawm 1000 yog 275mm;

Taw qhia rau Tsib Kev Tiv Thaiv Interlocking:

(1) Thaum lub tawb nqa khoom kaw rau hauv qhov chaw ua haujlwm ntawm lub txee, lub xauv electromagnet hauv lub chassis ntawm lub tawb nqa khoom raug kaw ntawm lub hau ntswj thiab yuav tsis raug rub los tiv thaiv lub tawb nqa khoom los ntawm kev rub lub Circuit Court breaker nrog load.

(2) Thaum lub hauv paus hloov pauv nyob rau hauv qhov chaw kaw, lub thawb pas nrig hauv kev sib cuam tshuam ntawm lub hauv paus hloov spindle raug thawb mus rau hauv lub tawb nqa khoom hauv lub txee, yog li cov khoom siv hluav taws xob sib txuas tsis tuaj yeem raug thawb mus rau hauv lub txee.

(3) Tom qab lub tshuab hluav taws xob hluav taws xob hluav taws xob kaw hauv qhov chaw ua haujlwm, sab nraud yog hluav taws xob, thiab qhov hloov hauv av tsis tuaj yeem raug kaw rau lub sijhawm no Lub laub pas nrig hauv kev sib cuam tshuam ntawm lub hauv paus hloov spindle yog thaiv, thiab nws txoj haujlwm tuav. tsis tuaj yeem ua haujlwm hauv av hloov spindle

(4) Rau cable nkag txee; Lub busbar seem txee thiab cov tswv yim transformer siv tau nruab nrog lub ntsuas hluav taws xob ntawm lub qhov rooj qis vim qhov hluav taws xob ntawm cov khoom siv hluav taws xob los xyuas kom meej tias chav cable tsis tuaj yeem nkag mus thaum lub cable sab yog hluav taws xob;

(5) Los ntawm kev txhim kho qhov yuam kev hloov pauv hloov pauv (nrog cov cim liab thiab ntsuab) ntawm lub vaj huam sib luag, nws muaj peev xwm tiv thaiv kev sib tsoo ntawm qhov qhib thiab kaw ntawm Circuit Court breaker.



6. Cov txheej txheem ua haujlwm

Kev siv hluav taws xob xa hluav taws xob:

Ua ntej nruab thiab tom qab ntawd kaw lub rooj tsavxwm, Kaw lub qhov rooj rau pem hauv ntej thiab qis dua - - - Ua haujlwm ntawm qhov hloov pauv hauv av thiab qhib nws - - - Siv lub tsheb hloov tsheb (platform tsheb) thawb lub laub (hauv lub xeev qhib ) mus rau hauv lub txee (kuaj txoj hauj lwm) - - - - Ntxig lub plug thib ob rau hauv lub qhov (socket) zoo li qub - - - (qhov ntsuas qhov ntsuas qhov ntsuas ntawm) - - - - - (kaw lub qhov rooj hauv ntej thiab nruab nrab) - - - - - Siv tus kov txhawm rau thawb lub laub los ntawm txoj haujlwm kuaj (qhib lub xeev) mus rau txoj haujlwm ua haujlwm - - - - (qhov taw qhia txoj haujlwm ua haujlwm rau, ntsuas qhov ntsuas qhov ntsuas tawm) ---------Kaw Circuit Court breaker handcart



Fais fab tuag (kev tu) kev ua haujlwm:

Qhib lub tshuab hluav taws xob hluav taws xob hluav taws xob hluav taws xob - - - - Siv tus kov kom tawm ntawm lub tawb nqa khoom los ntawm txoj haujlwm ua haujlwm (qhib lub xeev) mus rau qhov chaw sim - - - - (Qhov taw qhia txoj haujlwm ua haujlwm raug kaw, thiab qhov ntsuas qhov ntsuas tau qhib) - - - - Qhib lub qhov rooj nruab nrab sab pem hauv ntej - - - Rub tawm lub qhov txuas thib ob los ntawm lub qhov (socket) zoo li qub - - - (Qhov ntsuas qhov ntsuas qhov ntsuas tau raug kaw) - - - - - Siv lub tsheb hloov mus qhib lub tawb nqa khoom (nyob rau hauv lub xeev qhib) Tawm hauv lub txee ------- Siv lub hauv paus hloov spindle thiab kaw nws ------- Qhib lub rear sealing phaj thiab pem hauv ntej lub qhov rooj

★. Kev Ceeb Toom: Lub tsheb thauj neeg mob qis qis thiab nruab nrab (qis) PT handcart tuaj yeem rub ncaj qha tawm ntawm lub txee thaum lub sijhawm ua haujlwm busbar

Kev Pabcuam

◎ Ambient cua kub: -15 degree ~ ntxiv rau 40 degree ;

◎ txheeb ze av noo: nruab nrab txhua hnub 95 feem pua, thiab nruab nrab txhua hnub ntawm cov dej vapor siab <2.2kPa;

◎ Qhov nruab nrab txhua hli «90 feem pua, thiab txhua hli nruab nrab ntawm cov dej vapor siab <1.8kPa;

© Qhov siab: ^ 1000m;

◎ Seismic siv: tsis dhau Ms8.

◎ Cov huab cua nyob ib puag ncig yuav tsum tsis muaj kuab paug ntawm corrosive lossis flammable gas lossis vapor;

◎ Tsis pom kev vibration;

Main technical parameters
Rated voltage	.....................................	kV ua	3.6,7.2,12
Rated zaus	.....................................	Hz	50
Rated tam sim no ntawm Circuit Court breaker	.....................................	A	630/4000
Rated tam sim no ntawm switchgear	.....................................	A	630/4000
Rated luv-lub sij hawm tiv taus tam sim no (4S)	.....................................	kA	20,25,31.5,40
Rated ncov withstand tam sim no (peak)	.....................................	kA	50,63,80,100
Rated luv-circuit breaking tam sim no	.....................................	kA	20,25,31.5,40
Rated rwb thaiv tsev theem 1min zog zaus withstand voltage	Ncej-rau-ncej, ncej-rau- av	kV ua	24,32,42
	Nruab nrab ntawm kev sib cuag qhib	kV ua	24,32,48
Lightning impulse withstand voltage (nce)	Ncej-rau-ncej, ncej-rau- av	kV ua	40,60,75
	Nruab nrab ntawm kev sib cuag qhib	kV ua	46,70,85
Lub plhaub yog IP4X, thiab nws yog IP2X thaum lub qhov rooj qhov rooj thiab lub qhov rooj kaw qhov rooj qhib

Nta

1: Cov kauj ruam tiv thaiv nruj kom ntseeg tau tias muaj kev nyab xeeb ntawm tus kheej

2: Chav tsev cable tuaj yeem ntsia tau ntau npaum li 9 tus tub ntxhais cables

3: Kev khiav hauj lwm thiab kev soj ntsuam txoj haujlwm yuav raug tsim tsa rau lub laub, thiab ob txoj haujlwm tau nruab nrog kev ruaj ntseg thiab txhim khu kev qha cov cuab yeej thiab cov khoom siv.

4: Lub thawv ntim tau ua tiav los ntawm aluminized thiab galvanized steel phaj, uas yog machined thiab khoov los ntawm lub tshuab cuab yeej thiab ces bolted.

5: Nws muaj lub zog txhua yam thiab nws qhov zoo nkauj thiab kev zoo nkauj tau lees paub.

6: Lub qhov rooj switchboard yog txau nrog cov yas, kuj muaj lub peev xwm ntawm kev cuam tshuam thiab kev tiv thaiv corrosion.

7: Cov kev hloov pauv tseem ceeb tuaj yeem muab nrog VD4 lub tshuab nqus tsev vacuum thiab C3 series ntawm kev hloov pauv hloov ntawm ABB, ntau lub tshuab nqus tsev hluav taws xob hauv tsev (xws li VS1, VH1, VK, ZN28) kuj tseem tuaj yeem muab rau ntawm tib neeg txawv teb chaws. cov khoom.

8: Pem hauv ntej lub qhov rooj yog ntsia nrog lub qhov rais soj ntsuam xyuas cov kev khiav hauj lwm lub xeev ntawm cov khoom nyob rau hauv lub chav tsev

























Q5: Puas yog OEM / ODM muaj?

A: Yog, nws yog! Peb cov khoom tuaj yeem tsim kho. Peb muaj pab pawg tsim thiab engineers, peb tuaj yeem kho cov khoom raws li cov neeg siv khoom kos duab lossis cov kev xav tau.



Q6: Koj puas yog cov chaw tsim khoom lossis tuam txhab lag luam?
A: Peb yog lub Hoobkas, Raws li 100 feem pua ​​​​ntawm cov chaw tsim khoom nrog 20 xyoo kev tsim khoom, peb tuaj yeem tsim cov khoom raws li cov neeg siv khoom xav tau thiab peb tuaj yeem tswj cov khoom zoo 100 feem pua.



Q7: Tus nqi puas tuaj yeem sib tham?

A: Yog, tus nqi sib tham. Nws tuaj yeem hloov pauv raws li koj qhov ntau lossis pob



Q8: Ua li cas txog kev tshuaj xyuas?

A: Peb muaj tag nrho cov kev tshuaj xyuas los ntawm cov khoom siv raw mus rau qhov kawg cov khoom suav nrog kev ntsuas kub nce, ntsev tsuag tshuaj ntsuam xyuas tus neeg xyuas pib hom kev xeem, kev sim lub neej.



Q9: Cov nqe lus them nqi yog dab tsi?

A: TT, Paypal, Western Union, Alibaba kev lees paub kev lag luam thiab L / C tau txais. 30 feem pua ​​​​T / T ua ntej, 70 feem pua ​​​​ua ntej xa zaub mov.



Q10: Lub tuam txhab muab kev pabcuam yog dab tsi?

A: Peb muaj cov kws tshaj lij engineer pab pawg uas tuaj yeem tsim thiab tsim pwm kom tuaj txog cov neeg siv khoom sib txawv.

Peb kuj muaj pab pawg muag khoom los muab kev pabcuam zoo los ntawm kev muag khoom ua ntej mus rau tom qab muag.





Cov khoom no feem ntau yog customized.
Peb yog cov chaw tsim khoom thiab muaj lub tuam txhab kev tshaj lij uas tuaj yeem tsim thiab muab kev daws teeb meem raws li cov neeg siv khoom xav tau.
Thov nyem rau ntawm lub pob hauv qab no kom xa cov ntaub ntawv rau peb, thiab peb cov neeg muag khoom yuav tiv tauj koj los muab cov duab kos rau koj



Nov yog peb cov neeg siv khoom piv txwv rau koj siv

Uzbekistan cov neeg siv khoom

Cov ntaub ntawv
1.1 710-512-01-MVS1 Main Substation
Nkag mus Switchgear A01 B01 2
Tsis muaj Cheebtsam Specification Unit Qty Maker
1 VCB
HVX12-50-31-F 275 mm
Qhov siab tsawg dua lossis sib npaug li 2000m
Qhib voltage DC 220V
Kaw voltage DC 220V
Lub zog cia voltage DC220V
Teeb 1 Suav
2 VT JDZ-10 10KV/√3/0.1KV/√3 Set 3 China
3 CT ib
LZZBJ9-12 3000/1A 5P20 10VA
5P20 5VA 5Fs5 5VA
Teeb 3 Suav
4 High voltage fuse XRNP1-12 0.5A Pc 3 Tuam Tshoj
5 Hluav taws xob ntes HY5WZ-17/50 Teeb 3 Tuam Tshoj
6 Intelligent control panel WY-9008A Pc 1 China
7 Short circuit and ground fault indicator EKL-4-1 Pc 1 Suav teb
8 Multifunctional hluav taws xob ntsuas PD666-3S3 380V 5A Pc 1 Tuam Tshoj
9 Lub hauv paus harmonic eliminator LXQ-12KV Pc 1 Fengyuan
10 Charged zaub DXN-12Q Pc 1 China
11 Kub thiab av noo tswj WY-CS-III Pc 1 Tuam Tshoj
12 Txuas daim JY-2 Pc 3 Tuam Tshoj
13 Junction box PJ1 Pc 1 Tuam Tshoj
14 Metering bracket Universal hom Pc 1 Tuam Tshoj
15 teeb liab teeb liab ND16-22D/4 AC380V liab Pc 1 CHNT
16 teeb liab teeb ND16-22D/4 AC380V ntsuab Pc 1 CHNT
